35-350kW
GXE Series
Cost-Efficiency
Lower Capex, Minimal Opex
Flexible Deployment
Modular Design, Rapid Setup
Smart Operation
One-Touch, Plug-and-Play
Robust Performance
High Output, Extreme Reliability
Features
Smart GCC742 Control System
Advanced intelligence and automatic control capabilities
Up to 6,000 hours of continuous annual operation
Low investment cost and short payback period
Ask an Expert
PowerLink provides tailored, high-efficiency energy solutions for sustainable power around the world.
86-2157-858-099 ext 8820
info@powerlinkenergy.comGXE Series Parameter
| StructureType | Open type | Soundproof | Container Structure | Mini Container |
| Dimension(LxWxH), mm | 2640×1050×1530 | 2950*1200*1700 mm | 20/40 HQ Optional | |
| Noise level@7m,dB(A) | 84.2 | 62.2 | 60 | |
| Frequency | 50Hz / 60Hz | 50Hz / 60Hz | 50Hz / 60Hz | 50Hz / 60Hz |
| Voltage | 380V | 400V | 415V | 440V |
| Fuel Type | NG/BG | NG/BG | NG/BG | NG/BG |
GXE50C-Specification
DownloadGXE50C-Warranty Manual
GXE50C-Brochure Manual
GXE50C-Parts Manual
| StructureType | Open type | Soundproof | Container Structure | Mini Container |
| Dimension(LxWxH), mm | 2640×1050×1530 | 3000*1250*1700 mm | 20/40 HQ Optional | |
| Noise level@7m,dB(A) | 84.2 | 62.2 | 60 | |
| Frequency | 50Hz / 60Hz | 50Hz / 60Hz | 50Hz / 60Hz | |
| Voltage | 380V | 400V | 415V | 440V |
| Fuel Type | NG/BG | NG/BG | NG/BG | NG/BG |
GXE60C-Specification
GXE60C-Warranty Manual
GXE60C-Brochure Manual
GXE60C-Parts Manual
| StructureType | Open type | Soundproof | Container Structure | Mini Container |
| Dimension(LxWxH), mm | 3000×1100×1600 | 3000×1100×1600 | 20/40 HQ Optional | |
| Noise level@7m,dB(A) | 87 | 67.9 | 65 | |
| Frequency | 50Hz / 60Hz | 50Hz / 60Hz | 50Hz / 60Hz | |
| Voltage | 380V | 400V | 415V | 440V |
| Fuel Type | NG/BG | NG/BG | NG/BG | NG/BG |
GXE85C-Specification
GXE85C-Warranty Manual
GXE85C-Brochure Manual
GXE85C-Parts Manual
| StructureType | Open type | Soundproof | Container Structure | Mini Container |
| Dimension(LxWxH), mm | 3000×1100×1600 | 3140*1350*1800mm | 20/40 HQ Optional | |
| Noise level@7m,dB(A) | 87 | 67.9 | 65 | |
| Frequency | 50Hz / 60Hz | 50Hz / 60Hz | 50Hz / 60Hz | |
| Voltage | 380V | 400V | 415V | 440V |
| Fuel Type | NG/BG | NG/BG | NG/BG | NG/BG |
GXE100C-Specification
GXE100C-Warranty Manual
GXE100C-Brochure Manual
GXE100C-Parts Manual
| StructureType | Open type | Soundproof | Container Structure | Mini Container |
| Dimension(LxWxH), mm | 3345×1180×1718 | 3345×1180×1718 | 20/40 HQ Optional | |
| Noise level@7m,dB(A) | 91.1 | 72.9 | 70 | |
| Frequency | 50Hz / 60Hz | 50Hz / 60Hz | 50Hz / 60Hz | |
| Voltage | 380V | 400V | 415V | 440V |
| Fuel Type | NG/BG | NG/BG | NG/BG | NG/BG |
GXE130C-Specification
GXE130C-Warranty Manual
GXE130C-Brochure Manual
GXE130C-Parts Manual
| StructureType | Open type | Soundproof | Container Structure | Mini Container |
| Dimension(LxWxH), mm | 3350×1150×1680 | 3500*1400*1850mm | 20/40 HQ Optional | |
| Noise level@7m,dB(A) | 86.9 | 68 | 66 | |
| Frequency | 50Hz / 60Hz | 50Hz / 60Hz | 50Hz / 60Hz | |
| Voltage | 380V | 400V | 415V | 440V |
| Fuel Type | NG/BG | NG/BG | NG/BG | NG/BG |
GXE150C-Specification
GXE150C-Warranty Manual
GXE150C-Brochure Manual
GXE150C-Parts Manual
| StructureType | Open type | Soundproof | Container Structure | Mini Container |
| Dimension(LxWxH), mm | 3345×1180×1718 | 3500*1450*2050mm | 20/40 HQ Optional | |
| Noise level@7m,dB(A) | 91.1 | 72.9 | 70 | |
| Frequency | 50Hz / 60Hz | 50Hz / 60Hz | 50Hz / 60Hz | |
| Voltage | 380V | 400V | 415V | 440V |
| Fuel Type | NG/BG | NG/BG | NG/BG | NG/BG |
GXE200C-Specification
GXE200C-Warranty Manual
GXE200C-Brochure Manual
GXE200C-Parts Manual
| StructureType | Open type | Soundproof | Container Structure | Mini Container |
| Dimension(LxWxH), mm | 3745×1300×2050 | 4230*1560*2200mm | 20/40 HQ Optional | |
| Noise level@7m,dB(A) | 91.7 | 71.8 | 69 | |
| Frequency | 50Hz / 60Hz | 50Hz / 60Hz | 50Hz / 60Hz | |
| Voltage | 380V | 400V | 415V | 440V |
| Fuel Type | NG/BG | NG/BG | NG/BG | NG/BG |
GXE250C-Specification
GXE250C-Warranty Manual
GXE250C-Brochure Manual
GXE250C-Parts Manual
| StructureType | Open type | Soundproof | Container Structure | Mini Container |
| Dimension(LxWxH), mm | 5200X2000X2100 | 5400*2050*2500mm | 20/40 HQ Optional | |
| Noise level@7m,dB(A) | 89.7 | 75.2 | 73 | |
| Frequency | 50Hz / 60Hz | 50Hz / 60Hz | 50Hz / 60Hz | |
| Voltage | 380V | 400V | 415V | 440V |
| Fuel Type | NG/BG | NG/BG | NG/BG | NG/BG |
GXE350C-Specification
GXE350C-Warranty Manual
GXE350C-Brochure Manual
GXE350C-Parts Manual
Related Product
SL60K
High-efficiency outdoor lighting equipment, integrated with 1.5kWp PV panels and 14.3kWh energy storage battery, ensuring stable and...
Low-Pressure
LOW-PRESSURE / DISCHARGE PRESSURE：7-8BAR DIESEL AIR COMPRESSOR PowerLink’s diesel-powered mobile air compressor...
QSV Series
The QSV range of diesel generators, powered by PowerLink, Perkins, Kubota, and Cummins engines, provides 10 kVA to 2500 kVA for...
ACG Series
Micro-CHP unit is a miniaturized distributed energy equipment. It uses a single fuel such as natural gas and biogas as power, and usable heat.
FAQ
Can our gas unit be connected in parallel with the existing diesel engine on site?
Technically feasible, but gas and diesel are flammable and explosive fuels, which need to be safely isolated and non-standard design according to the specifications.
Is it feasible for two gas units to be installed in one container in parallel?
Our company has done the design project of parallel installation of two diesel generator sets in a container, and the design of two gas units in parallel in a container is technically feasible, and the specific design needs to be carried out according to the actual working conditions.
Is the unit control screen an Scada screen and can it be equipped with an HDMI interface?
Our unit cannot provide Scada screens, which are rarely used in the industrial field. Besides, we cannot provide HDMI interfaces either. We only provide interfaces such as USB, RS485 or RS232.
Does the gas valve assembly have a filtering function?
Our gas valve groups, whether single solenoid valves or double solenoid valves, all contain filters that can further filter and purify combustible gas.
Can natural gas and biogas be directly switched for a gas turbine unit?
It is not recommended to use natural gas and biogas as two types of fuel in the same gas unit. Their calorific values are different, and power drop will occur atier switching.
